Gigabit Switch 16 Port ( TP-LİNK )

Gigabit Switch 16 Port ( TP-LİNK )
Görsel 1
Fiyat:
80,00 USD + KDV
İndirimli Fiyat (%8,8) :
73,00 USD + KDV
Kazancınız 7,00 USD
KDV Dahil:
3.727,38 TL
Aynı Gün Kargo Kargo Bedava

Ürüne Oy Verin

DONANIM ÖZELLİKLERİ
Standartlar ve Protokoller IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z,
IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s,
IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Arabirim 16 10/100/1000Mbps RJ45 Ports
(Auto-Negotiation/Auto MDI/MDIX)
2 Combo 100/1000Mbps SFP Slots
Ağ Medyası 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable
(maximum 100m)
100BASE-FX: MMF, SMF
1000BASE-X: MMF, SMF
Fan Sayısı Fanless
Güç Kaynağı 100~240VAC, 50/60Hz
Güç Tüketimi Maximum: 14.4W (220V/50Hz)
Boyutlar ( W X D X H ) 17.3* 7.1* 1.7 in. (440* 180* 44 mm)
PERFORMANS
Bandwidth/Backplane 32Gbps
Paket Yönlendirme Hızı 23.8Mpps
MAC Adres Tablosu 8k
Jumbo Frame 10240 Bytes
YAZILIM ÖZELLİKLERİ
Quality of Service Support 802.1p CoS/DSCP priority
Support 4 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting
Voice VLAN
L2 Özellikleri IGMP Snooping V1/V2/V3
802.3ad LACP (Up to 6 aggregation groups,
containing 4 ports per group)
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loop back detection
802.3x Flow Control
VLAN Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)
Erişim Kontrol Listesi L2?L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports
Güvenlik SH v1/v2
SSL v2/v3/TLSv1
Port Security
Broadcast/Multicast/Unknown unicast Storm Control
802.1x and Radius Authentication?IP-Mac-Port-VID Binding?ARP Inspection?DHCP Snooping?DoS Defend
Yönetim Web-based GUI and CLI management
SNMP v1/v2c/v3, compatible with public MIBs and
TP-LINK private MIBs
RMON (1, 2, 3, 9 groups)
CPU Monitoring
Port Mirroring
Time Setting: SNTP
Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS
DİĞERLERİ
Sertifika CE, FCC, RoHS
Paket İçeriği TL-SG2216
Power Cord
Installation Guide
Resource CD
Rackmount Kit
Rubber Feet
Sistem Gereksinimleri Microsoft® Windows® XP, Vista™ or Windows 7, Windows 8, MAC® OS, NetWare®, UNIX® or Linux.
Ortam Operating Temperature: 0?~40? (32?~104?);
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Diğer Özellikler
Stok Kodu0074
MarkaTP-LİNK
Stok DurumuVar
Garanti (Yıl)2
